E-Catalog > เครื่องมือช่าง > SP231-400VAC-DP Rhomberg Slimline Voltage Window Comparator

PAGE VIEW : 24,351

Product Information :

Name :
SP231-400VAC-DP Rhomberg Slimline Voltage Window Comparator
Category :
  1. เครื่องจักร, อุปกรณ์เกี่ยวกับเครื่องจักร, เครื่องมือกล
Sub - Category :
  1. เครื่องมือช่าง
Brand :
RHOMBERG
Model :
SP-231-400VAC-DP Slimline Voltage Window
Product Type :
  1. สินค้า, ผลิตภัณฑ์
Short Description :
SP231 Rhomberg Slimline Voltage Window Comparator Brand : RHOMBERG Type : SP-231-400VAC-DP Slimline Voltage Window Supplier : Srinutch Components Co.,Ltd. Website : www.srinutch.com Email.: srinutch@gmail.com Spec. คลิกเอกสารแนบ + ไฟล์เอกสาร (ด้านล่างครับ)

Product Detail :

Features

  • SP231 monitors 3 Phases only, SP232 monitors 3 Phases and Neutral
  • 11-pin plug-in.
  • Fail-to-safe design.
  • Combined overvoltage and undervoltage monitoring.
  • Monitoring of own supply voltage (3 phase).
  • Separately adjustable setpoints: over-voltage, (5 to 20%) and, under-voltage (-5 to -20%).
  • Adjustable response time on trip (0.1 to 10 seconds).
  • Fixed hysteresis: 2%.
  • Fixed start-up delay for disabling latching 10 sec.
  • Selectable latching (ie manual or auto reset).
  • LED indication of Relay ON and fault type.
  • 10A SPDT relay output.
  • Supersedes SP230.
  • Requires optional S3-B 11-pin base.
